LM-A3500 3.5 m³ All-in-One
Integrated frame, drum swings 270° — built for punishing terrain.
Key specifications
Full technical table below. Optional engines and configurations on request — tell us your site conditions and target price.
Get Full Spec Sheet
LM-A3500 highlights
The LM-A3500 moves the drum onto a one-piece engineering chassis. The integrated frame raises load capacity and torsional fatigue strength, so the machine keeps its geometry under full load on bumpy, muddy and dust-heavy sites.
The cab stays fixed while the drum swings right through 270°, giving the driver a very clear sense of direction — a configuration many customers already know and trust for canal lining and long-strip pours.
- One-piece engineering chassis — higher load & anti-torsion capacity
- Fixed cab for precise, stable driving feel
- Drum swings right through 270° for fan-shaped pouring
- Excellent for canal lining: set the angle, drive forward evenly
- 3.5 m³ per batch on 12R22.5 steel-wire tires
- Rexroth drum motor and Borrego closed reducer
Full technical specifications
| General | |
| Overall dimension (L×W×H) | 7500 × 2900 × 3400 mm |
| Wheelbase | 2600 mm |
| Operating weight | 8,800 kg |
| Driving form | Four-wheel drive (4WD) |
| Max. speed | 35 km/h |
| Max. gradeability | 35° |
| Min. turning radius | 4,000 mm |
| Min. ground clearance | 340 mm |
| Brake | Spring-applied air-release brake |
| Powertrain | |
| Engine | Yuchai 4105 turbocharged diesel |
| Rated power | 85 kW (115.6 hp) |
| Transmission | ZL-300 hydraulic torque converter |
| Gears | 4 forward / 4 reverse, dual high-low speed |
| Fuel tank | 120 L |
| Hydraulic oil tank | 120 L |
| Engine oil | 16 L |
| Hydraulic system | |
| Reducer | Borrego 230B closed type |
| Main pump | Plunger pump R1-40/80 |
| Drum motor | Rexroth |
| Drum rotation speed | 17 rpm |
| Water & mixing | |
| Water tank | 800 L |
| Water supply | Timed relay, auto shut-off; hydraulic self-priming pump |
| Drum geometric capacity | 5.5 m³ |
| Concrete output per batch | 3.5 m³ |
| Running gear | |
| Tires | 12R22.5 steel-wire tires, front 2 + rear 4 |
Specifications may be optimized continuously; the commercial contract prevails. Custom colors, engines and attachments available.
Photo gallery
